Geographic Analysis with Census Data
This example demonstrates how to work with geographic census data, including creating maps and performing spatial analysis.
Import required libraries
import pycancensus as pc
import matplotlib.pyplot as plt
import pandas as pd
# Set up the plotting style
plt.style.use('default')
plt.rcParams['figure.figsize'] = (12, 8)
Getting Geographic Census Data
Let’s retrieve census data with geographic boundaries for mapping.
print("Retrieving geographic census data...")
try:
# Get population data with geometries for Vancouver CMA
geo_data = pc.get_census(
dataset="CA21",
regions={"CMA": "59933"}, # Vancouver CMA
vectors=["v_CA21_1", "v_CA21_434"], # Population and median income
level="CT", # Census Tract level for detailed analysis
geo_format="geopandas"
)
print(f"Retrieved {len(geo_data)} census tracts")
print(f"Columns: {list(geo_data.columns)}")
except Exception as e:
print(f"Error retrieving data: {e}")
print("Creating sample data for demonstration...")
# Create sample data for demonstration when API is not available
import numpy as np
from shapely.geometry import Point
import geopandas as gpd
# Sample coordinates around Vancouver area
n_points = 50
np.random.seed(42)
lons = np.random.uniform(-123.3, -122.9, n_points)
lats = np.random.uniform(49.15, 49.35, n_points)
geo_data = gpd.GeoDataFrame({
'GeoUID': [f'59933{i:03d}' for i in range(n_points)],
'name': [f'Census Tract {i}' for i in range(n_points)],
'v_CA21_1': np.random.randint(1000, 8000, n_points), # Population
'v_CA21_434': np.random.randint(30000, 120000, n_points), # Median income
'geometry': [Point(lon, lat) for lon, lat in zip(lons, lats)]
}, crs='EPSG:4326')
print("Using sample data for demonstration")
Retrieving geographic census data...
📋 Request Preview:
Dataset: CA21
Level: CT
Regions: 1 region(s)
Variables: 2 vector(s)
Geography: geopandas
🔍 Estimated Size: medium (200 rows)
⏱️ Expected Time: 5-15 seconds
Downloading 200 regions with geography...
✅ Retrieved 535 regions with 2 variables (1.0s)
Retrieved 535 census tracts
Columns: ['geometry', 'a', 'q', 't', 'dw', 'hh', 'id', 'pop', 'dw16', 'hh16', 'name', 'rpid', 'ruid', 'pop16', 'rguid', 'v_CA21_1: Population, 2021', 'v_CA21_434: Occupied private dwellings by structural type of dwelling data']
Creating a Basic Map
Let’s create a simple map showing population distribution.
fig, ax = plt.subplots(1, 1, figsize=(12, 10))
# Create choropleth map of population
if 'v_CA21_1' in geo_data.columns:
geo_data.plot(
column='v_CA21_1',
cmap='YlOrRd',
legend=True,
ax=ax,
legend_kwds={'label': 'Population', 'shrink': 0.8}
)
ax.set_title('Population Distribution by Census Tract\nVancouver CMA, 2021',
fontsize=16, pad=20)
ax.set_xlabel('Longitude')
ax.set_ylabel('Latitude')
# Remove axes ticks for cleaner look
ax.tick_params(labelsize=10)
plt.tight_layout()
plt.show()
Multi-variable Analysis
Let’s compare two variables: population and median income.
if 'v_CA21_1' in geo_data.columns and 'v_CA21_434' in geo_data.columns:
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(16, 7))
# Population map
geo_data.plot(
column='v_CA21_1',
cmap='YlOrRd',
legend=True,
ax=ax1,
legend_kwds={'label': 'Population', 'shrink': 0.8}
)
ax1.set_title('Population by Census Tract')
ax1.axis('off')
# Median income map
geo_data.plot(
column='v_CA21_434',
cmap='YlGnBu',
legend=True,
ax=ax2,
legend_kwds={'label': 'Median Income ($)', 'shrink': 0.8}
)
ax2.set_title('Median Income by Census Tract')
ax2.axis('off')
plt.suptitle('Vancouver CMA: Population vs Income Distribution',
fontsize=16, y=1.02)
plt.tight_layout()
plt.show()
Statistical Analysis
Let’s perform some basic statistical analysis on our geographic data.
if 'v_CA21_1' in geo_data.columns and 'v_CA21_434' in geo_data.columns:
print("\nStatistical Summary:")
print("="*50)
# Population statistics
pop_stats = geo_data['v_CA21_1'].describe()
print("Population Statistics:")
print(f" Mean: {pop_stats['mean']:.0f}")
print(f" Median: {pop_stats['50%']:.0f}")
print(f" Std Dev: {pop_stats['std']:.0f}")
print(f" Range: {pop_stats['min']:.0f} - {pop_stats['max']:.0f}")
# Income statistics
income_stats = geo_data['v_CA21_434'].describe()
print(f"\nMedian Income Statistics:")
print(f" Mean: ${income_stats['mean']:,.0f}")
print(f" Median: ${income_stats['50%']:,.0f}")
print(f" Std Dev: ${income_stats['std']:,.0f}")
print(f" Range: ${income_stats['min']:,.0f} - ${income_stats['max']:,.0f}")
# Correlation analysis
correlation = geo_data['v_CA21_1'].corr(geo_data['v_CA21_434'])
print(f"\nCorrelation between Population and Income: {correlation:.3f}")
Scatter Plot Analysis
Let’s visualize the relationship between population and income.
if 'v_CA21_1' in geo_data.columns and 'v_CA21_434' in geo_data.columns:
fig, ax = plt.subplots(1, 1, figsize=(10, 8))
scatter = ax.scatter(
geo_data['v_CA21_1'],
geo_data['v_CA21_434'],
c=geo_data['v_CA21_1'],
cmap='viridis',
alpha=0.7,
s=60
)
ax.set_xlabel('Population')
ax.set_ylabel('Median Income ($)')
ax.set_title('Population vs Median Income\nVancouver CMA Census Tracts')
# Add colorbar
cbar = plt.colorbar(scatter, ax=ax)
cbar.set_label('Population')
# Add trend line
z = np.polyfit(geo_data['v_CA21_1'], geo_data['v_CA21_434'], 1)
p = np.poly1d(z)
ax.plot(geo_data['v_CA21_1'], p(geo_data['v_CA21_1']),
"r--", alpha=0.8, linewidth=2)
plt.tight_layout()
plt.show()
Working with Different Geography Levels
Census data is available at different geographic levels. Let’s compare a few.
print("\nComparing Geographic Levels:")
print("="*40)
levels_to_try = ["CMA", "CSD", "CT"]
level_names = ["Metro Area", "Municipality", "Census Tract"]
for level, name in zip(levels_to_try, level_names):
try:
# Get count of regions at each level
regions = pc.list_census_regions("CA21", level=level)
print(f"{name} ({level}): {len(regions)} regions")
except:
print(f"{name} ({level}): Unable to retrieve")
Comparing Geographic Levels:
========================================
Metro Area (CMA): Unable to retrieve
Municipality (CSD): Unable to retrieve
Census Tract (CT): Unable to retrieve
Advanced Mapping with Folium
For interactive maps, we can use folium (when available).
try:
import folium
from folium import plugins
print("\nCreating interactive map with Folium...")
# Create base map centered on Vancouver
center_lat = geo_data.geometry.centroid.y.mean()
center_lon = geo_data.geometry.centroid.x.mean()
m = folium.Map(
location=[center_lat, center_lon],
zoom_start=10,
tiles='OpenStreetMap'
)
# Add choropleth layer
if 'v_CA21_1' in geo_data.columns:
folium.Choropleth(
geo_data=geo_data,
data=geo_data,
columns=['GeoUID', 'v_CA21_1'],
key_on='feature.properties.GeoUID',
fill_color='YlOrRd',
fill_opacity=0.7,
line_opacity=0.2,
legend_name='Population'
).add_to(m)
print("Interactive map created successfully!")
print("(Map object created but not displayed in static documentation)")
except ImportError:
print("Folium not available - install with: pip install folium")
except Exception as e:
print(f"Error creating interactive map: {e}")
Creating interactive map with Folium...
Interactive map created successfully!
(Map object created but not displayed in static documentation)
Summary and Next Steps
This example demonstrated key geographic analysis capabilities:
print("\n" + "="*60)
print("Geographic Analysis Example Complete")
print("="*60)
print("\nWhat we covered:")
print("• Retrieving census data with geographic boundaries")
print("• Creating choropleth maps with matplotlib")
print("• Multi-variable geographic visualization")
print("• Statistical analysis of spatial data")
print("• Scatter plot analysis of geographic variables")
print("• Working with different geographic levels")
print("• Interactive mapping with Folium")
print("\nNext steps for your analysis:")
print("1. Experiment with different census variables")
print("2. Try different geographic levels (CMA, CSD, CT, DA)")
print("3. Combine multiple datasets for temporal analysis")
print("4. Use spatial analysis tools from geopandas")
print("5. Create interactive dashboards with your maps")
============================================================
Geographic Analysis Example Complete
============================================================
What we covered:
• Retrieving census data with geographic boundaries
• Creating choropleth maps with matplotlib
• Multi-variable geographic visualization
• Statistical analysis of spatial data
• Scatter plot analysis of geographic variables
• Working with different geographic levels
• Interactive mapping with Folium
Next steps for your analysis:
1. Experiment with different census variables
2. Try different geographic levels (CMA, CSD, CT, DA)
3. Combine multiple datasets for temporal analysis
4. Use spatial analysis tools from geopandas
5. Create interactive dashboards with your maps
Additional Resources
For more advanced geographic analysis, consider exploring:
geopandas: Advanced spatial operations and analysis
folium: Interactive web maps
plotly: Interactive plotting and dashboards
contextily: Adding basemaps to static plots
rasterio: Working with raster data
pysal: Spatial analysis library
